Duplicate of Rif-cs Schema - Testing Draft
Test 14.3. Schema Element Descriptions
<accessPolicy> Element
A URL describing service access policies. This could be a web site or XACML resource for example.
Contained within: service
<accessRights> Element
Used to describe access rights and access constraints, including who may access and when access may occur (including any embargo). Restrictions may be based on security, privacy or other policies. A free text statement may be provided. Preferably, choose a type from the accessRights type vocabulary.
Examples:
Access is restricted to the project participants until six months after the completion of the project.
Available from 11.30am AEST 9 February 2010
Not for release before 7.30pm AEST 13 May 1997
Contained within: rights
Attributes:
type: optional
A value taken from the Access Rights Type vocabulary.
rightsUri: optional
A URI pointing to access rights and constraints relating to the registry object.
<activity> Element
Wrapper element for descriptive and administrative metadata for an activity registry object.
May contain: description (registryObject) | identifier (registryObject) | location | name | relatedInfo | relatedObject | subject
Contained within: registryObject
Attributes:
type: required
A value taken from the Activity Type vocabulary.
dateModified: optional
The date this object's metadata was last changed. This only refers to the metadata of the registry object itself. For example if a collection has a new item added to it this does not constitute a modification to the object.
<address> Element
Wrapper element for physical and electronic address metadata.
May contain: physical | electronic
Contained within: location
Registry Objects
This element holds either a full or partial address. Multiple addressPart elements may be used to divide the full address into meaningful fragments (e.g. street address, postcode, country).
Contained within: physical
Attributes:
type: required
A value taken from the Physical Address Part Type vocabulary
<arg> Element
The arg element is used to describe the arguments for an electronic service. In an ANDS Collections Registry context this element must not be used when describing activity, collection or party objects.
Contained within: electronic
required: required
Indicates whether the argument is required (true) or optional (false).
type: required
A value taken from the Arg Type vocabulary.
use: optional
A value taken from the Arg Use vocabulary.
<byteSize> Element
The byteSize element can be used to specify the size of an electronic target.
Contained within: electronic
<citationInfo> Element
Wrapper element for citation metadata related to a registry object. Citation metadata can be represented as a single block of text by using the <fullCitation> element or it can be broken down into a more granular structure by using the <citationMetadata> element.
May contain: fullCitation | citationMetadata
Contained within: collection
Registry Objects ( 0-n)
This element holds either a full or partial address. Multiple addressPart elements may be used to divide the full address into meaningful fragments (e.g. street address, postcode, country).
Contained within: physical
Attributes:
type: required
A value taken from the Physical Address Part Type vocabulary
